The mysterious Martian potato: An experimental investigation into the origin of Phobos

Background: Despite extensive study, the Mars system still possesses many mysteries, one of which is the formation of its moons Phobos and Deimos. Several mechanisms have been proposed but weather the moons formed as re-accreted ejecta [1] or as captured asteroids [2]) remains a significant problem. The key to solving this is currently thought to be held in the analysis of Phobosian ejecta, with numerical models having predicted it to contain, on average, 255 ppm of Martian material contaminant [3,4], transported to Phobos via impact processes.

Whilst numerical investigations have provided ranges for the level of detectable Martian material on Phobos [3,4,5,6], laboratory investigations are required into both the level of Martian material predicted on the surface of Phobos and its assumed detectability. Whilst some studies have previously found distinguishing features during spectral analysis of Phobosian surface analogues [7], an experimental investigation utilizing complex geological mixtures is lacking. This study therefore performed an experimental test of the assumed detectability of Martian material through the use of a geologically complex ‘Martian’ projectile impacting a geologically complex Phobos simulant target.

Method: The work presented here assumes the case of a captured asteroid origin for Phobos. It presents the results from a shot series aiming to quantify the level of projectile material detectable during post-shot analysis. Six shots were carried out using the one and two stage light-gas gun at the University of Kent[10,11] over the speed range of 650 m/s to 1600 m/s covering the lower end of speeds predicted for material impacting the surface of Phobos [5]. The projectiles were designed to maximize the quantity of projectile material reaching the target and were formed of a custom designed 3D-printed UV-cured resin shell (Figure 1) containing an Eu-doped MGS-1 (Martian simulant) [8] mixture.

This design of projectile allowed a geologically complex Martian simulant material to be used, with minimal preparation required, thus reducing chemical changes to the projectile. This was fired at cemented PCA-1 (Phobosian simulant) [9] target blocks (Figure 2) forming a geologically complex analogue of the Phobosian near-surface region. Targets were cubes with an average side length of 8.6 cm and depth of 5.8 cm. The average porosity was calculated to be 9.6% just is on the lower end of the current porosity range of 10-50% estimated for Phobos [1].

Post-shot analysis focused on two main questions: 1) can material from a Martian projectile be detected, and 2) can the level of detected material be quantified. For this, ejecta material was captured during each shot through the use of an ejecta capture cell. Not all of the ejecta from each shot was captured, but it is assumed that the material collected is representative of the entire population. Analysis was carried out on the ejecta sample and resultant impact crater separately, allowing the distribution of Martian contaminant material within the Phobosian regolith and the implantation of projectile material to be investigated separately.

Collected ejecta samples were subjected to XRF, and XRD analysis, to both confirm and attempt to quantify the presence of projectile. To aid in the post-shot identification of projectile material, an elemental tracer (in the form of Eu(CH3CO2)3·XH2O) was included in the projectile. XRF analysis of the pre-impact material (Figure 3) shows clear differences between the PCA-1 and MGS-1 materials. Not only is the europium content of the projectile significantly higher than the background levels within the PCA-1 or MGS-1 simulants, characteristic variations between the two simulants (with differences being found between the measured K2O, Cr2O3, and NiO values) are also evident. Whilst the initial results show the clear presence of projectile material within the collected ejecta, further in-depth analysis is required to quantity its level. Initial observations of the impact features also shows the presence of projectile material (see Figure 4 and Figure 5).

Conclusions: This study has demonstrated the ability to effectively fire a geologically complex ‘Martian’ projectile and subsequently detect this material within the impact target and ejecta. A full analysis of the targets and ejecta is now underway, with the aim of quantifying the level of successful transfer of impactor to the target. If successful this would provide an experimental test of previous numerical studies investigating the formation of Phobos.
